Overview
Using fourth-generation LoRa® IP supporting both terrestrial and SATCOM networks in the sub-GHz, 2.4 GHz ISM bands and licensed S-band. The transceiver is designed to be backward compatible with previous LoRa devices, ensuring seamless LoRaWAN® compatibility. The device additionally features expanded physical layer modulations for fast long-range communication (FLRC) and is compatible with various low-power wireless protocols including Amazon Sidewalk, W-MBUS, Wi-SUN FSK, and Z-Wave when integrated with third-party stack offerings. The LR2021 features an advanced RF and analog architecture that supports a multi-region, single-SKU design, reducing external BOM costs, PCB footprint, and power consumption, while offering superior performance compared to previous LoRa transceivers.
Features
Key features of the LoRa Plus™ LR2021 include:
- Terrestrial and NTN, sub-GHz, 2.4 GHz ISM bands and licensed S-band radio
- Multi-PHY compatibility enables LP wireless protocols with third-party stacks
- FLRC up to 2.6 Mbps, LoRa up to 200 kbps, FSK, OOK, O-QPSK and LR-FHSS modulations
- Multi-region operation with single switch-less front-end design
- +22 dBm to -10 dBm Transmitter, offering best-in-class energy efficiency
- Multi-SF Receiver with low noise figure, Improved CAD and best LoRa sensitivity down to -142 dBm @ SF12/125 kHz
- Increased frequency offset tolerance obviating TCXO and large thermal relief
| Documents | Release Date | Type |  |
|---|---|---|---|
| LR2021 Datasheet v1.1 | 2025-10-21 | | |
| AN1200.103 LR2021 CPFSK Modem Improvements v1.0 | 2025-10-23 | | |
| AN1200.112 FLRC Regulatory Measurement Reports v1.0 | 2025-10-23 | | |
| AN1200.114 LR2021 Ranging Demo v1.0 | 2025-10-23 | | |
| AN1200.59 - Selecting the Optimal Reference Clock | 2025-09-15 | | |
| Documents | Release Date | Type | |
|---|---|---|---|
| LoRa Studio - PC based evaluation tool | 2025-10-23 | TXT | |
| LoRa Studio Windows Installation file | 2025-10-16 | TXT | |
| Production files for Wio-LR2021 490 MHz & 2.4GHz Evaluation Module (Pending certification) | 2025-10-21 | ZIP | |
| Production files for Wio-LR2021 868/915 MHz & 2.4GHz Evaluation Module (Pending certification) | 2025-10-06 | ZIP | |
