TDS2211P
Transient diverting suppressors (TDS), part of the SurgeSwitch™ portfolio, are designed to provide protection against electrical overstress events (EOS). These devices have superior clamping and stability over temperature when compared to standard transient voltage suppressor (TVS) devices.
Features
- Transient protection for:
- IEC 61000-4-2 (ESD) ±30kV (air), ±30kV (contact)
- IEC 61000-4-4 (EFT) ±4kV (100kHz & 5kHz, 5/50ns)
- IEC 61000-4-5 (Surge) 40A (8/20µs)
- IEC 61000-4-5 (Surge) ±1kV (1.2/50µs)
- Protects one I/O or power line
- Working voltage: 22V
- Constant clamping voltage across the rated peak pulse current range and temperature range
- High peak pulse current capability: 40A (tp = 8/20μs)
- DFN 1.6mm x 1.6mm x 0.55mm 6-Lead
- USB PD
- USB Type-C
- Internet of Things (IoT) devices
- Storage devices
- Industrial equipment
- Notebook and tablet computers
- Load switch input protection
Applications
Packaging
- 6-pin DFN: 1.6 x 1.6 x 0.55mm
Order Codes
- TDS2211P.C: Pb-free, halogen-free, RoHS/WEEE-compliant, 3,000 pcs.
