Semtech Expands its RClamp® Platform with a Versatile TVS Array for Safeguarding Industrial and Telecommunications Electronics
RClamp0504FB provides best-in-class transient voltage protection for data circuits in a variety of electronic systems
CAMARILLO, Calif., February 13, 2020 – Semtech Corporation (Nasdaq: SMTC), a leading supplier of high performance analog and mixed-signal semiconductors and advanced algorithms, today announced the latest addition to its RClamp® platform. The four-line, 5V RClamp0504FB offers robust electrostatic discharge (ESD) protection and superior surge immunity in an industry standard six lead SC-70 package. This transient voltage suppression (TVS) array offers extensive interface protection versatility with its differentiated performance and small form factor enabling use in data ports for industrial, Internet of Things (IoT) and telecommunication applications.
Exceeding industry standards for ESD immunity, the RClamp0504FB offers a 28A Ipp surge rating and is housed in a compact SC-70 package. This footprint presents hardware designers PCB space savings and the familiarity of an established multi-line package. The RClamp0504FB offers an extremely low typical capacitance of 1.1pF, making the device well suited for use in high speed differential interfaces.
“As silicon transceivers continue to scale to smaller geometries, the vulnerability of present day microelectronic devices to overvoltage and surge threats is among the highest it has been in the industry’s history,” said Timothy Puls, Product Marketing Director for Semtech’s Protection Products Group. “The RClamp0504FB is an extremely flexible device that gives hardware engineers an outstanding, versatile solution for protecting a broad range of data interfaces from some of the harshest ESD and surge threats.”
Key Features of the RClamp0504FB
- Transient protection for high-speed data lines to: IEC 61000-4-2 (ESD) ±30kV (contact), ±24kV (air); IEC 61000-4-4 (EFT) 40A (5/50ns); IEC 61000-4-5 (lightning) 28A (8/20μs)
- 5V bi-directional working voltage protection
- High surge capability: 28A (tp=8/20μs)
- Protects 4 I/O lines
- Low capacitance (1.1 pF typical)
- SC-70 package
- Pb-free and RoHS/WEEE compliant
Pricing and Availability
The RClamp0504FB (order code: RClamp0504FB.TCT) is available immediately in production quantities. Semtech offers comprehensive design assistance, including field- and factory-based support. Data sheets, volume pricing and delivery quotes, as well as evaluation kits and samples, are available by contacting firstname.lastname@example.org.
About Semtech’s Circuit Protection Products
Semtech provides reliable system-level Electrostatic Discharge (ESD) and Electromagnetic Interference (EMI) circuit protection solutions that meet the industry's toughest requirements. Semtech ESD protection diodes feature low clamping voltage, low capacitance and low leakage current to protect your system interconnects from external ESD threats. Semtech’s portfolio of circuit protection products include the RClamp®, EClamp®, µClamp®, and TClamp® families of products, among others. For more information, visit the Semtech Circuit Protection site.
