The LoRa® Corecell gateway Fine Timestamp reference design is a complete indoor and outdoor gateway turnkey solution reference design provided for US, EU and China ISM bands. The reference design is based on SX1303.
No evaluation kit available for purchase
Available reference design file package
- Fine Timestamp
- 10x power reduction compared to legacy products
- Maximum TX output power (CN490) = +17dBm
- Maximum TX output power (EU868/US915) = +27dBm
- Receive 8 LoRa channels multi-data rates (SF5 ~ SF12 / 125 simultaneously kHz) + 2 mono-data rate (LoRa 250/500kHz and FSK 50kbps)
- Typical sensitivity level (CN490):
- -141dBm at SF12 BW 125kHz
- -12dBm at SF7 BW 125kHz
- -110dBm at FSK 50kbps
- Typical sensitivity level (EU868/US915):
- -140dBm at SF12 BW 125kHz
- -125dBm at SF7 BW 125kHz
- -110dBm at FSK 50kbps
- Home automation
- Building automation
- Factory automation
Datasheets & Documentation
Explore software downloads, documentation, recommended links, and more resources for this product.
HAL & Packet Forwarder on Github
