The GN1812 is the latest generation of 56GBd, quad, linear, transimpedance amplifier (TIA) designed for 400Gbps Ethernet operation using PAM4 modulation and optimized for PIN photodiodes.
- Supports 56GBd PAM4 operation per lane
- Low IRN
- High bandwidth
- MGC and AGC modes with programmable gain/output swing
- Output swing level detector
- Receive signal strength indicator (1:4)
- Hardware global LOS based on RSSI status of all channels
- Per channel LOS based on RSSI of individual channel (digital)
