Semtech SC4216H
Very Low Input /Very Low Dropout 3 Amp Linear Regulator With Enable
The SC4216H is a high performance positive voltage regulator designed for use in applications requiring very low input voltage and very low dropout voltage at up to 3 amperes.
Overview
Features - Input Voltage as low as 1.45V
- 500mV dropout @ 3A
- Adjustable output from 0.5V
- Over current and over temperature protection
- Enable pin
- 10μA quiescent current in shutdown
- Full industrial temperature range
- Available in SOIC-8-EDP Lead-free package, fully WEEE and RoHS compliant
Applications - Telecom/Networking cards
- Motherboards/Peripheral cards
- Industrial applications
- Wireless infrastructure
- Set top boxes
- Medical equipment
- Notebook computers
- Battery powered systems
Packaging- SOIC-8-EDP
Order Codes - SC4216HSETRT: Lead-Free, WEEE and RoHS Compliant, 2,500 pcs, Tape and Reel Only
- SC4216HEVB: SC4216H Evaluation Board
- Telecom/Networking cards
- Motherboards/Peripheral cards
- Industrial applications
- Wireless infrastructure
- Set top boxes
- Medical equipment
- Notebook computers
- Battery powered systems
Packaging- SOIC-8-EDP
Order Codes - SC4216HSETRT: Lead-Free, WEEE and RoHS Compliant, 2,500 pcs, Tape and Reel Only
- SC4216HEVB: SC4216H Evaluation Board
- SC4216HSETRT: Lead-Free, WEEE and RoHS Compliant, 2,500 pcs, Tape and Reel Only
- SC4216HEVB: SC4216H Evaluation Board
Diagrams and Specs
Block Diagram
Click diagram to enlarge
