Semtech EZ1086I
1.5 Amp Positive Voltage Regulator
The EZ1086 series of high performance positive voltage regulators are designed for use in applications requiring low dropout performance at up to 1.5A. Additionally, the EZ1086 series provides excellent regulation over variations in line, load and temperature.
Overview
Features - Low dropout voltage: 1.4 V max.
- Full current rating over line and temperature
- Fast transient response
- ± 2% total output regulation over line, load, and temperature
- Adjust pin current max. 90 μA over temperature
- Line regulation typically 0.015%
- Load regulation typically 0.05%
- Industrial temperature range
- TO-220 and TO-263 packages
Applications - Post regulators
- Battery chargers
Packaging
- Post regulators
- Battery chargers
Packaging
TO-263, TO-220
Order Codes - EZ1086IM.TR: Package Minimum Tape & Reel Only
- EZ1086IT: $500.00 min.line Bulk (50 pcs.increments)
Diagrams and Specs
Block Diagram
Click diagram to enlarge
