SC4520
Not Recommended for New Designs
Not recommended for new designs.
Features
- Wide operating voltage range: 4.4V to 24V
- Integrated 3 Amp switch
- 100kHz to 600kHz adjustable frequency operation
- Current mode control
- Precision enable threshold
- SO-8 EDP package. Lead-free product, fully WEEE and RoHS compliant
- XDSL modems
- CPE equipment
- DC-DC point of load applications
- Portable equipment
- Digtial consumer electronics
Applications
Packaging
- SO-8 EDP
Order Codes
- SC4520SETRT: Lead-free, RoHS and WEEE compliant, 2500 pcs. Tape & Reel
Pb(Lead)-Free/RoHS-Green Info
Base Part Number (1)
SC4520
Part Description
3A STEP-DOWN SWITCHING REGULATOR WITH ADJUSTABLE SWITCHING FREQUENCY
# of leads
8
Package Type
SOIC EDP
Pb-Free (2)
YES
Reflow Temp °C (3)
260
Lead or Ball Finish
MATTE Sn
MSL Rating
1
REACH SVH C(233) EC1907/2006 (18)
YES Download Report
JIG 101 A & B (12)
YES
YES Download Report
RoHS 2/3 Amend 2015/863 (7)
YES Download Report
WEEE 2012/19/EU (19)
YES
China RoHS 2 GB/T 26572-2011
YES Download Report
Halogen Free / Low IEC 61249-2-21/JS709C (20)
YES Download Report
Proposition 65 (21)
YES Download Report
Packaging Material 94/62/EC (17)
YES Download Report
RoHS Compliant by Exception (8)
NO
Whisker Testing (10)
Thermal Cycling Whisker Test
(-40°C to +85°C / 4000 cycles)
(-40°C to +85°C / 4000 cycles)
YES
Ambient Temperature Storage, Whisker Test
(50°C, 4000 Hrs)
(50°C, 4000 Hrs)
YES
60°C/90%RH 4000 Hrs, Whisker Test
YES
Declarations and Reports
IPC-1752-2
mySemtech
