Semtech’s New RClamp® Array Provides Industry-Leading Protection for LVDS, Ethernet and USB 3.x Interfaces

RClamp3324P leverages Semtech’s proprietary technology capabilities to clamp 25 to 50 percent lower than similar products on the market

CAMARILLO, Calif., July 24, 2019Semtech Corporation (Nasdaq: SMTC), a leading supplier of analog and mixed-signal semiconductors and advanced algorithms, today announced the latest addition to the RClamp® platform, a low capacitance 3.3V (Vrwm) transient voltage protection array optimized to safeguard high-speed data interfaces from electrostatic discharge (ESD) and overvoltage transient threats.

“Today’s high-speed data circuits are increasingly vulnerable to damage or latch-up from common electrostatic transients. Providing system robustness through lower clamping voltage protection solutions is critical,” said Tee Lim, Product Marketing Director for Semtech’s Protection Products Group. “RClamp3324P leverages many of Semtech’s proprietary technology capabilities to offer product designers a device that clamps 25 to 50 percent lower than similar products on the market today.”

The four-line, 3.3V RClamp3324P offers designers increased protection margin by offering an exceptionally low ESD clamping voltage while minimizing loading capacitance to protect high-speed data interfaces, including LVDS, Ethernet and USB 3.x. Additionally, the RClamp3324P, housed in a 10-pin QFN package, facilitates a flexible flow-through layout ideal for optimizing trace routing to achieve signal integrity performance. The device exceeds the ESD requirements of the IEC61000-4-2 ESD immunity standard, achieving ±20kV air and ±17kV contact.

Key Features of the RClamp3324P

  • Transient protection for high-speed data lines to: IEC 61000-4-2 (ESD) ±20kV (air), ±17kV (contact); IEC 61000-4-4 (EFT) 4kV (5/50ns); IEC 61000-4-5 (lightning) 4.5A (8/20μs)
  • 3.3V working voltage protection
  • Protects four I/O lines
  • Low capacitance (<0.4pF typical line-to-line)
  • QFN package: 2.5 x 1.0 x 0.6 mm
  • Pb Free and RoHS/WEEE compliant

Pricing and Availability

The RClamp3324P (order code: RClamp3324P.TCT) is available immediately in production quantities. Semtech offers comprehensive design assistance, including field- and factory-based support. Data sheets, volume pricing, and delivery quotes, as well as evaluation kits and samples are available by contacting info@semtech.com.

About Semtech’s Circuit Protection Products

Semtech provides reliable system-level Electrostatic Discharge (ESD) and Electromagnetic Interference (EMI) circuit protection solutions that meet the industry's toughest requirements. Semtech ESD protection diodes feature low clamping voltage, low capacitance and low leakage current to protect your system interconnects from external ESD threats. Semtech’s portfolio of circuit protection products include the RClamp®, EClamp®, µClamp®, and TClamp® families of products, among others. For more information, visit the Semtech Circuit Protection site.

About Semtech

Semtech Corporation is a leading supplier of analog and mixed-signal semiconductors for high-end consumer, computing, communications and industrial equipment. Products are designed to benefit the engineering community as well as the global community. The company is dedicated to reducing the impact it, and its products, have on the environment. Internal green programs seek to reduce waste through material and manufacturing control, use of green technology and designing for resource reduction. Publicly traded since 1967, Semtech is listed on the NASDAQ Global Select Market under the symbol SMTC. For more information, visit www.semtech.com.
