Semtech to Launch its GS12070 UHD-SDI Gearbox for Next Generation UHDTV Infrastructures at the NAB Show 2016
Semtech to demonstrate how its UHD-SDI Gearbox will help drive industry UHDTV infrastructure adoption

Semtech to Launch its GS12070 UHD-SDI Gearbox for Next Generation UHDTV Infrastructures at the NAB Show 2016

Semtech to demonstrate how its UHD-SDI Gearbox will help drive industry UHDTV infrastructure adoption (Booth N5024)

Camarillo, California - April 14, 2016 -

Semtech Corporation (Nasdaq: SMTC), a leading supplier of analog and mixed-signal semiconductors, today announced the GS12070 UHD-SDI Gearbox , an advanced integrated circuit (IC) for next generation UHDTV infrastructures.

The GS12070 features single-chip UHD-SDI rate conversion and enables equipment manufacturers and broadcasters to take a standards-based, commercial off-the-shelf approach to UHDTV infrastructures, minimizing the risk of interoperability issues.

Next generation UHDTV infrastructures, in addition to requiring seamless conversion between different UHD-SDI formats, will require integration with existing SDI infrastructures. The GS12070 seamlessly converts between HD-SDI, 3G, 6G and 12G UHD-SDI interface profiles. Alternative conversion technologies require equipment manufacturers to license third-party IP cores at an additional expense or develop in-house intellectual property solutions with increased development, schedule and interoperability risks.

“UHD-SDI is the ideal interface for UHDTV infrastructures,” said Don Shaver, Director of Video Marketing for Semtech’s Signal Integrity Product Group. “Broadcasters are demanding a fully standardized, interoperable, commercial off-the-shelf technology for their next-generation UHDTV infrastructures, and the GS12070 Gearbox is uniquely positioned to enable these demanding requirements today.”

Semtech’s booth (N5024) at the National Association of Broadcasters (NAB) Show on April 18-21 at the Las Vegas Convention Center will feature a dedicated, public Gearbox Zone to demonstrate the GS12070’s features and benefits, as well as key UHDTV gearbox applications from Semtech.

Key Features of the GS12070

  • Fully integrated gearbox solution: Four-input and four-output IC supporting conversions between multi-link, dual-link and single-link UHD-SDI interfaces. Support for 12G, 6G, 3G and HD line rates to maximize compatibility with existing SDI infrastructures.
  • Automatic link ordering: Automatic link ordering for multi-link interfaces simplifies integration and automatically compensates for UHD-SDI cabling issues that often arise during installation.
  • Automatic skew correction: In the most common conversion modes, automatic compensation for channel skew, an unavoidable system challenge in multi-link UHD-SDI systems, exceeds the Society of Motion Picture & Television Engineers’ (SMPTE) recommended skew tolerance specification. This minimizes the need for additional system resources and simplifies the overall system design.
  • Integrated 4x4 crosspoint switch: Enables signal routing from any of the four 12G UHD-SDI inputs to any of the four 12G UHD-SDI outputs making it an ideal choice for UHDTV routing and distribution amplifier applications.
  • Small form factor: Simplifies design integration and application compatibility.



The GS12070 will be available for sale the second half of 2016. Semtech offers comprehensive design assistance, including field- and factory-based support. Data sheets, volume pricing and delivery quotes, as well as evaluation kits and samples, are available at
