Semtech Announces the Industry’s First Single Chip Hybrid PLC and LoRa® Wireless Platform for Smart Grid, Smart Metering and IoT Applications
The EV8600 PLC+RF+LoRa Platform enables dual Phy AMI Networks with wireless capability
Camarillo, California - May 3, 2016 -
Semtech Corporation (Nasdaq: SMTC), a leading supplier of analog and mixed-signal semiconductors, announced today the availability of its new EV8600 dual modem (PLC+RF System-on-Chip) with integrated LoRa™ wireless RF technology. The Semtech EV8600 is the first fully integrated PLC and LoRa modem for smart grid, smart metering and IoT applications. The advanced features of the EV8600 help reduce network operational costs of Advance Metering Infrastructures (AMI) by up to 50 percent. In addition, the revolutionary EV8600 modem enables seamless LoRa gateway network deployment of Internet of Things (IoT) solutions for smart city and industrial automation.
By offering both a Power Line Communications (PLC) modem operating at 10-500KHZ and a Radio Frequency (RF) modem operating in the range of 142-1050MHz, Semtech’s industry-leading EV8600 enables virtually 100 percent connectivity coverage with a single chip. The EV8600 also offers a LoRa fallback mode in the event of a complete network outage caused by a natural disaster or other unforeseen events.
“The integration of Semtech LoRa technology in the EV8600 enables critical access for network operators and provides further reliability in network operations. It helps eliminate the ‘1 percent Problem’ in AMI networks, where the cost of reaching the 1 percent Hard-to-Reach Nodes can account for as much as 50 percent of the entire AMI network operational cost,” said Reza Mirkhani, Vice President of Smart Grid Products for Semtech’s Wireless and Sensing Product Group. “We already see AMI networks migrating to PLC+RF Dual PHY architectures to achieve as close to 100 percent coverage as possible. The addition of LoRa to EV8600 enables each end node to become a LoRa gateway, servicing LoRa-based devices and back hauling their data over the PLC network.”
To simplify the design effort, Semtech’s LoRa-enabled EV8600 series performs all bridging/routing algorithms between the two internal modems and has embedded dual image flash memory. The implementation of LoRa features into the new Semtech’s EV8600 is accompanied by the addition of Wireless M-BUS protocol for sub-metering applications.
About the EV8600 Single-Chip Hybrid PLC+RF Solution
The EV8600 features highly integrated dual-modem System-on-Chip (SoC) comprising a PLC modem and a sub-GHz RF transceiver, all in a single chip with internal secure flash memory. It also includes an applications processor with bridging and routing algorithms between PLC and RF modems. Additional features:
- PLC modem
- Integrated AF
- Dual Processor MAC & Network architecture
- Multi-standard: G3-PLC, PRIME, P1901.2 and S-FSK
- Programmable frequency range from 9KHz-490KHz
- Multi-band: CENELEC, FCC, ARIB
- RF modem
- LoRa Modem, WMBUS, 802.15.4g
- 168 dB maximum link budget
- +20 dBm - 100 mW constant RF output vs. V supply
- +14 dBm high efficiency PA
- Programmable bit rate up to 300 kbps
- High sensitivity: down to -148 dBm
- Bullet-proof front end: IIP3 = -11 dBm
- Excellent blocking immunity
- Low RX current of 9.9 mA, 200 nA register retention
- Fully integrated synthesizer with a resolution of 61 Hz
- FSK, GFSK, MSK, GMSK, LoRa and OOK modulation
- Built-in bit synchronizer for clock recovery
- Preamble detection
- 127 dB Dynamic Range RSSI
- Automatic RF Sense and CAD with ultra-fast AFC
- Packet engine up to 256 bytes with CRC
- Built-in temperature sensor and low battery indicator
